Plasma Consumables 120792 , Plasma Cutter Swril Ring

5pcs
MOQ
negotiation
Price
 Plasma Consumables 120792 , Plasma Cutter Swril Ring
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Plasma Consumables
Application: Plasma Cutting Machine
Standard: Manufacturer Production Standard
TypeElectrode 220435: Swirl Ring 120792
High Light:

plasma cutting nozzle

,

plasma cutting consumables

Basic Infomation
Place of Origin: China
Brand Name: Plasma Consumables
Certification: ROHS/ SGS
Model Number: Swirl Ring 120792
Payment & Shipping Terms
Packaging Details: Manufacturer packing
Delivery Time: Prompt goods
Payment Terms: T/T or western Union
Supply Ability: 10,000pcs per month
Product Description

HT4400 Swril Ring 120792, Plasma Cutter Swril Ring ,Plasma Machine Swirl Ring



FAQ:



Q1:Can I get a free samples to check the quality?



A:Sure,we can supply the free samples but you need bear the express cost by yourself.



Q2:Will I afford the carrier charge?



A:Yes,you will afford the express charge or your account is OK.



Q3:Can I add my trademark on my products?



A:Yes,we need your certificate of authorization.



 Plasma Consumables 120792 , Plasma Cutter Swril Ring 0

 Plasma Consumables 120792 , Plasma Cutter Swril Ring 1


Machine HEC NO. Ref NO. Description




















HT4400

H04785 120785 Electrode,Oxygen,100Amp
H04793 120793 Electrode,Oxygen,200Amp
H04802 120802 Electrode,Oxygen,300Amp
H04810 120810 Electrode,Oxygen,400Amp
H04855 120855 Electrode,Nitrogen,200/400Amp
H74783 120783 Swirl Ring,Oxygen,100Amp
H74784 120784 Swirl Ring,Oxygen,100Amp,CCW
H74791 120791 Swirl Ring,Oxygen,200Amp
H74792 120792 Swirl Ring,Oxygen,200Amp,CCW
H74913 120913 Swirl Ring,Oxygen,300Amp
H74914 120914 Swirl Ring,Oxygen,300Amp,CCW
H74939 120939 Swirl Ring,Oxygen,400Amp
H74940 120940 Swirl Ring,Oxygen,400Amp,CCW
H74853 120853 Swirl Ring,Nitrogen,200/400Amp
H14777 120777 Nozzle,Oxygen,100Amp
H14778 120778 Nozzle,Oxygen,100Amp,CCW
H14787 120787 Nozzle,Oxygen,200Amp
H14788 120788 Nozzle,Oxygen,200Amp,CCW
H14794 120794 Nozzle,Oxygen 300/Nitrogen 200Amp
H14795 120795 Nozzle,Oxygen 300/Nitrogen 200Amp,CCW
H14934 120934 Nozzle,Oxygen,400Amp
H14935 120935 Nozzle,Oxygen,400Amp,CCW
H14856 120856 Nozzle,Nitrogen,400Amp
H14857 120857 Nozzle,Nitrogen,400Amp,CCW
H44786 120786 Retaining Cap,100/200/300/400Amp
H44907 120907 Retaining Cap,100/200/300/400Amp With HIS Tab
H44786 120786 Retaining Cap,100/200/300/400Amp
H44984 120984 Retaining Cap,100/200/300/400Amp Under Water
H84651 120651 Torch Main Body
H94025 120025 Water cooling tube
H94028 044028 O-ring










HT 4001

H04285 020285 Electrode,N2
H04663 020663 Electrode,Oxygen,260Amp
H04630 120630 Electrode,Oxygen,340Amp
H74039 020039 Swirl Ring,N2,120/166/187
H74040 020040 Swirl Ring,N2
H74623 020623 Swirl Ring,Oxygen
H74135 120135 Swirl Ring,Oxygen,340Amp
H14281 020281 Nozzle,N2
H14282 020282 Nozzle,N2
H14283 020283 Nozzle,N2
H14284 020284 Nozzle,N2
H14086 020086 Nozzle,Oxygen
H44580 020580 Retaining Cap,N2
H44579 020579 Retaining Cap
H44185 120185 Retaining Cap,Oxygen,50Amp





Technical Support:
A

Plasma cutting machine matters needing attention



The selection of cutting parameters of CNC plasma cutting machine is very important for cutting quality, cutting speed and efficiency. The correct use of CNC plasma machine for high quality fast cutting, cutting process parameters must be deeply understood and mastered.



First, cutting current: it is the most important cutting process parameters, directly determines the cutting thickness and speed, that is, cutting ability. Effects: 1, cutting current increases, an increase in the energy of the arc, cutting ability, the cutting speed is increased; 2, cutting current increases, increasing the diameter of the arc arc variable rough makes incision width; 3, cutting current ambassador to the nozzle increases the heat load, the nozzle premature damage, cutting quality of the natural decline, can't even normal cut. So the cutting current and the corresponding nozzle should be chosen according to the thickness of the material before cutting.



Second, cutting speed: best cutting speed range according to equipment illustrate selected or test to determine, due to the thickness of the material, different materials, high melting point, thermal conductivity and melting the surface tension and other factors, the cutting speed is also a corresponding change. The main performance: 1, cutting speed can be improved to improve the quality of the cut, that is slightly narrow incision, incision surface more smooth, and can reduce the deformation. 2, the cutting speed is too fast that cutting line energy lower than the required value, cut seam in the jet can't quickly melted cutting melt immediately blew and the formation of larger drag, accompanied by incision slag hanging, the surface quality of the incision down. 3, when the cutting speed is too low, because the cut is plasma arc anode, in order to maintain the stability of the arc's, anode spot or anode region must from recent arc cutting seam found near the conduction current place, at the same time will pass more heat to a radial jet, so make the incision became wide, on both sides of the notch of molten material in the bottom flange aggregation and coagulation, form is not easy to clean the slag hanging, and incision margin due to excessive heating and melting and the formation of fillet. 4, when the speed is very low, because the cut is too wide, the arc will even put out. It can be seen that good cutting quality and cutting speed can not be separated.
