Nozzle 020608 For Max200 Plasma Consumables Plasma Cutting
We can offer you all plasma consumables for , Kjellberg, Esab, Koike, Komatsu, Thermadyne, such as: electrode, nozzle, shield, swirl ring, inner cap, retaining cap, water tube, torch body and so on.
We are a professional manufacturer of plasma cutter consumables, Our company is located in the Shanghai City, China ,it was established in 2007,but we had 10 years manufacturing experience in this field, the new factory covers an area of more than 10000 square meters .There are 50-100 workers and 20 research engineers.
| Machine | HEC NO. | Ref NO. | Description |
|
MAX200 HT2000 |
H02021 | 220021 | Electrode,Oxygen/Air,40/200Amp |
| H02547 | 120547 | Electrode,Oxygen/Air,100Amp | |
| H02667 | 120667 | Electrode,Oxygen/Air,40/200Amp | |
| H72833 | 120833 | Swirl Ring,Oxygen,200Amp | |
| H72617 | 020617 | Swirl Ring,Oxygen,100Amp | |
| H72607 | 020607 | Swirl Ring,Air,Argon/Hydrogen,N2,100/200Amp | |
| H12605 | 020605 | Nozzle,Oxygen,200Amp | |
| H12608 | 020608 | Nozzle,Oxygen,Air,Argon/Hydrogen,N2,200Amp | |
| H12611 | 020611 | Nozzle,Air,Argon/Hydrogen,100Amp | |
| H42423 | 020423 | Retaining Cap,40/100/200Amp | |
| H42837 | 120837 | Retaining Cap ,40/100/200Amp | |
| H22424 | 020424 | Shield,Oxygen,Air,N2,200Amp | |
| H22448 | 020448 | Shield,Oxygen,Air,Argon/Hydrogen,100Amp | |
| H82380 | 128380 | Machine Torch Assembly | |
| H82584 | 120584 | MAX200/HT2000Torch body | |
| H92383 | 028383 | Torch Lead | |
| H92384 | 028384 | Torch Lead | |
| H92894 | 120894 | Torch Mounting Sleeve | |
| H92963 | 020963 | Water tube, Standard | |
| H92027 | 044027 | O-Ring |
Technical Support:
Plasma cutting technology
1 cutting torch and workpiece perpendicular to
If the cutting torch and the material is not vertical, will cut out the angled slot. From the two aspects to check if the torch and workpiece angle of 90 degrees.
2 confirm the cutting direction
The good side is always on the cutting surface along the direction of walking on the right side of the torch (assuming the use of vortex ring is right)
