Kaliburn Plasma Torch Nozzle 277120 , Kaliburn Plasma Cutter Consumables
We are a manufacture professional engaged in plasma cutting consumables for man than 10 years.
Our products can be replaced: , Kjellberg, Koike, Komatsu, Esab, Kaliburn, , Thermadyne, OTC and other brands of plasma cutting machine accessories.
We can supply you like Electrode, Nozzle, Nozzle Cap, Shield, Shield cap, Swirl ring, Inner Retaining Cap, Outer Retaining Cap, Water Cooling Tube and so on.
| 277284 | Nozzle | 100A (MS, SS-A, AL) | |
| 277287 | Nozzle | 200A (SS-H17) | |
| 277289 | Nozzle | 200A (MS, SS-A, AL) | |
| 277293 | Nozzle | 150A (MS, SS-A, AL) | |
| 277297 | Nozzle | 150A (SS-H17) | |
| 279489 | Nozzle (for Silver) | 200A (MS, SS-A, AL) silver configuration only | |
| 279469 | Nozzle 275A (for Silver) | 275A (MS, AL) silver configuration only | |
| 284125 | Nozzle | 400A (MS) | |
| 284157 | Nozzle | 400A (SS-A, AL) | |
| 284158 | Nozzle | 400A (SS-H17) | |
| 277138 | Swirl Ring | 30A (SS-A) | |
| 277130 | Electrode Copper | 30A (MS, AL) | |
| 277131 | Electrode Copper | 50/70A (MS, AL), 70A (SS-A) | |
| 277132 | Electrode Copper | 70A (SS-H17) | |
| 277133 | Electrode Copper | 100A (SS-H17) | |
| 277135 | Electrode Copper | 150/200/260A (SS-H17) | |
| 277137 | Electrode Copper | 30/50A (SS-A) | |
| 277270 | Electrode Copper | 275A (MS, SS-A, AL) | |
| 277282 | Electrode Copper | 100A (MS, SS-A, AL) | |
| 277291 | Electrode Copper | 200A (MS, SS-A, AL) | |
| 277292 | Electrode Copper | 150A (MS, SS-A, AL) | |
| 279440 | Electrode Silver | 200A (MS, SS-A, AL) silver configuration only | |
| 279450 | Electrode Silver | 275A (MS, AL) silver configuration only | |
| 279460 | Electrode Silver | 400A (MS) silver configuration only | |
| 284124 | Electrode Copper | 400A (MS) | |
| 284159 | Electrode Copper | 400A (SS-A, SS-H17, AL) | |
| 277000 | Standard Torch | T4 Standard Torch | |
Technical Support:
1 the thickness of the perforation should be within the scope of the plasma system.
Cutting machine can not be perforated over the thickness of the plate, usually the thickness of the normal thickness of the thickness of the cutting 1/2. For example: the 100A plasma system for cutting 1 inches (about 25mm) of carbon steel, the system perforation thickness should be 0.5 inches (about 12.5mm).
2 nozzles do not overload
Let the nozzle overload (that is, over the working current of the nozzle), the nozzle will soon be damaged. The current intensity should be 95% of the working current of the nozzle. For example: 100 the current intensity of the nozzl.
