Plasma Retaining Cap 220818 PMX85 Consumables ROHS / SGS

Plasma Retaining Cap 220818 PMX85 Consumables ROHS / SGS

Plasma Retaining Cap 220818  PMX85 Consumables ROHS / SGS

Product Details:

Place of Origin: China
Brand Name: Plasma Consumables
Certification: ROHS/ SGS
Model Number: 220818 Retaining Cap

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: negotiation
Packaging Details: Manufacturer packing
Delivery Time: Prompt goods
Payment Terms: T/T or western Union
Supply Ability: 10,000pcs per month
Contact Now
Detailed Product Description
Product Name: Plasma Consumables Application: Plasma Cutting Machine
Standard: Manufacturer Production Standard Type: 220818 Retaining Cap
High Light:

plasma torch parts


plasma cutter parts

220818 Retaining Cap For PowerMax85 Plasma Consumables


            We can offer you all plasma consumables for , Kjellberg, Esab, Koike, Komatsu, Thermadyne, such as: electrode, nozzle, shield, swirl ring, inner cap, retaining cap, water tube, torch body and so on.

           We are specialized in the production of plasma cutting machine torch consumables manufacturer, we are engaged in the industry for ten years.

           Our products are processed using CNC machines, we have fifteen sets of high-precision testing equipment and Eighty experienced skilled workers.




Machine HEC NO. Ref NO. Description











PowerMAX 45

PowerMAX 65

PowerMAX 85

PowerMAX 105


H71857 220857 Swirl Ring 45/65/85Amp
H71994 220994 Swirl Ring 45/65/85/105Amp
H71947 220947 Swirl Ring FineCut
H01842 220842 Electrode 45/65/85Amp
H11941 220941 Nozzle 45Amp
H11819 220819 Nozzle 65Amp
H11816 220816 Nozzle 85Amp
H11930 220930 Nozzle FineCut
H11797 220797 Nozzle 65A/85A gouging
H11990 220990 Nozzle 105Amp
H11991 220991 Nozzle 105A gouging
H41854 220854 Retaining Cap 45/65/85Amp
H41953 220953 Retaining Cap 45/65/85A mechanized, ohmic
H41817 220817 Shield 45/65/85Amp mechanized
H41818 220818 Shield 45/65/85A drag-cutting
H41948 220948 Shield FineCut, mechanized, ohmic
H41798 220798 Shieldg 65/85A gouging
H41931 220931 Deflector FineCut, handheld
H41993 220993 Shield 105Amp mechanized
H41798 220798 Shield 105A drag-cutting
H91955 220955 Deflector 45/65/85A mechanized,unshielded



Technical Support:

The problem of plasma cutting



5.3 The poor quality of cutting


Is cut not to wear the workpiece, or hang slag, slotted uneven. This is main arc has not been sufficient compression, arc column thicker, the penetration problems caused by, main reason is cutting gas pressure is insufficient or cutting gas pipeline leakage. Combined electromagnetic valve control cutting gas, combination switch and trachea, if the use of imitation of the parameters of the nozzle, wrong, cause the turbulence between the nozzle electrode will also be the case.


5.4 spark generator can't be broken arc


Plasma cutting machine work, first of all to ignite the plasma arc, by the high frequency oscillator excited gas between the electrode and the inner wall of the nozzle, resulting in high-frequency discharge, the gas ionization and the formation of local small arc, the small arc by compressed air and ejected from the nozzle to ignite the plasma arc, which is main task spark generator. Under normal circumstances, the spark generator working time is only 0. 5 ~ 1s, the reason does not automatically break arc is generally offset control circuit board components, discharge electrode gap of the spark generator is not right. Should always check the spark generator discharge electrode, make the surface smooth, timely adjustment of the discharge electrode gap spark generator (0. From 8 to 1. 2mm), it is necessary to change control board.
