HT4400 / HT4001 Plasma Consumables For Plasma Cuttting Machine

HT4400 / HT4001 Plasma Consumables For Plasma Cuttting Machine

    • HT4400 / HT4001  Plasma Consumables For   Plasma Cuttting Machine
    • HT4400 / HT4001  Plasma Consumables For   Plasma Cuttting Machine
    • HT4400 / HT4001  Plasma Consumables For   Plasma Cuttting Machine
  • HT4400 / HT4001  Plasma Consumables For   Plasma Cuttting Machine

    Product Details:

    Place of Origin: China
    Brand Name: Plasma Consumables
    Certification: ROHS/ SGS
    Model Number: HT4400 / HT4001

    Payment & Shipping Terms:

    Minimum Order Quantity: 5pcs
    Price: negotiation
    Packaging Details: Manufacturer packing
    Delivery Time: Prompt goods
    Payment Terms: T/T or western Union
    Supply Ability: 10,000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Plasma Consumables Application: Plasma Cutting Machine
    Standard: Manufacturer Production Standard Type: HT4400 / HT4001
    High Light:

    max 200 parts


    plasma cutting consumables

    HT4400 / HT4001 Plasma Torch Consumables For Plasma Cuttting Machine
                We can offer you all plasma consumables for , Kjellberg, Esab, Koike, Komatsu, Thermadyne, such as: electrode, nozzle, shield, swirl ring, inner cap, retaining cap, water tube, torch body and so on.
               Each of our products has been tested with a rigorous precision instrument, A large number of piercings tests and service life tests, And made batch trial in our customers. If all results are good, then we will producing them.

             We are a professional manufacturer of plasma cutter consumables, Our company is located in the Shanghai City, China ,it was established in 2007,but we had 10 years manufacturing experience in this field, the new factory covers an area of more than 10000 square meters .There are 50-100 workers and 20 research engineers.

    Machine HEC NO. Ref NO. Description



















    H04785 120785 Electrode,Oxygen,100Amp
    H04793 120793 Electrode,Oxygen,200Amp
    H04802 120802 Electrode,Oxygen,300Amp
    H04810 120810 Electrode,Oxygen,400Amp
    H04855 120855 Electrode,Nitrogen,200/400Amp
    H74783 120783 Swirl Ring,Oxygen,100Amp
    H74784 120784 Swirl Ring,Oxygen,100Amp,CCW
    H74791 120791 Swirl Ring,Oxygen,200Amp
    H74792 120792 Swirl Ring,Oxygen,200Amp,CCW
    H74913 120913 Swirl Ring,Oxygen,300Amp
    H74914 120914 Swirl Ring,Oxygen,300Amp,CCW
    H74939 120939 Swirl Ring,Oxygen,400Amp
    H74940 120940 Swirl Ring,Oxygen,400Amp,CCW
    H74853 120853 Swirl Ring,Nitrogen,200/400Amp
    H14777 120777 Nozzle,Oxygen,100Amp
    H14778 120778 Nozzle,Oxygen,100Amp,CCW
    H14787 120787 Nozzle,Oxygen,200Amp
    H14788 120788 Nozzle,Oxygen,200Amp,CCW
    H14794 120794 Nozzle,Oxygen 300/Nitrogen 200Amp
    H14795 120795 Nozzle,Oxygen 300/Nitrogen 200Amp,CCW
    H14934 120934 Nozzle,Oxygen,400Amp
    H14935 120935 Nozzle,Oxygen,400Amp,CCW
    H14856 120856 Nozzle,Nitrogen,400Amp
    H14857 120857 Nozzle,Nitrogen,400Amp,CCW
    H44786 120786 Retaining Cap,100/200/300/400Amp
    H44907 120907 Retaining Cap,100/200/300/400Amp With HIS Tab
    H44786 120786 Retaining Cap,100/200/300/400Amp
    H44984 120984 Retaining Cap,100/200/300/400Amp Under Water
    H84651 120651 Torch Main Body
    H94025 120025 Water cooling tube
    H94028 044028 O-ring










    HT 4001

    H04285 020285 Electrode,N2
    H04663 020663 Electrode,Oxygen,260Amp
    H04630 120630 Electrode,Oxygen,340Amp
    H74039 020039 Swirl Ring,N2,120/166/187
    H74040 020040 Swirl Ring,N2
    H74623 020623 Swirl Ring,Oxygen
    H74135 120135 Swirl Ring,Oxygen,340Amp
    H14281 020281 Nozzle,N2
    H14282 020282 Nozzle,N2
    H14283 020283 Nozzle,N2
    H14284 020284 Nozzle,N2
    H14086 020086 Nozzle,Oxygen
    H44580 020580 Retaining Cap,N2
    H44579 020579 Retaining Cap
    H44185 120185 Retaining Cap,Oxygen,50Amp

    HT4400 / HT4001  Plasma Consumables For   Plasma Cuttting Machine 0

    Technical Support:
     The problem of plasma cutting


    5.3 The poor quality of cutting


    Is cut not to wear the workpiece, or hang slag, slotted uneven. This is main arc has not been sufficient compression, arc column thicker, the penetration problems caused by, main reason is cutting gas pressure is insufficient or cutting gas pipeline leakage. Combined electromagnetic valve control cutting gas, combination switch and trachea, if the use of imitation of the parameters of the nozzle, wrong, cause the turbulence between the nozzle electrode will also be the case.


    5.4 spark generator can't be broken arc


    Plasma cutting machine work, first of all to ignite the plasma arc, by the high frequency oscillator excited gas between the electrode and the inner wall of the nozzle, resulting in high-frequency discharge, the gas ionization and the formation of local small arc, the small arc by compressed air and ejected from the nozzle to ignite the plasma arc, which is main task spark generator. Under normal circumstances, the spark generator working time is only 0. 5 ~ 1s, the reason does not automatically break arc is generally offset control circuit board components, discharge electrode gap of the spark generator is not right. Should always check the spark generator discharge electrode, make the surface smooth, timely adjustment of the discharge electrode gap spark generator (0. From 8 to 1. 2mm), it is necessary to change control board.
