Professional PT-36 Plasma Cutting Machine 0558006010 Esab Plasma Cutter Parts

Professional PT-36 Plasma Cutting Machine 0558006010 Esab Plasma Cutter Parts

  • Professional PT-36 Plasma Cutting Machine 0558006010 Esab Plasma Cutter Parts
  • Professional PT-36 Plasma Cutting Machine 0558006010 Esab Plasma Cutter Parts
Professional PT-36 Plasma Cutting Machine 0558006010 Esab Plasma Cutter Parts
Product Details:
Place of Origin: China
Brand Name: Plasma Consumables
Certification: ROHS/ SGS
Model Number: 0558006010
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: negotiation
Packaging Details: Manufacturer packing
Delivery Time: Prompt goods
Payment Terms: T/T or western Union
Supply Ability: 10,000pcs per month
Contact Now
Detailed Product Description
Product Name: Plasma Consumables Application: Plasma Cutting Machine
Standard: Manufacturer Production Standard Type: 0558006010
High Light:

esab plasma cutter parts


esab spare parts

Plasma Cutter Nozzle 0558006010 1.0mm For Esab PT-36 Plasma Cutting Machine accessories
Shanghai ZhouBo Welding & Cutting Technology is a professional manufacturer plasma consumables electrode, nozzle, shield, swirl ring, inner cap, retaining cap, water tube, torch body and so on. We have tens years experience to export many countries, and our products is very competitive in the world.
Each of our products has been tested with a rigorous precision instrument, A large number of piercings tests and service life tests, And made batch trial in our customers. If all results are good, then we will producing them.

0558003914 Electrode
0558005459 Electrode L.C., O2/N25
0558003928 Electrode Std., O2/H355
0558009400 Electrode
0558009406 Nozzle 0.6mm
0558009410 Nozzle 1.0mm
0558009411 Nozzle 1.1mm
0558008010 Nozzle 1.0mm
0558006010 Nozzle 1mm
0558006014 Nozzle 1.4mm
0558006018 Nozzle 1.8mm
0558006020 Nozzle 2mm
0558006023 Nozzle 2.3mm
0558006025 Nozzle 2.5mm1
0558006030 Nozzle 3mm1
0558006036 Nozzle 3.6mm1
0558006041 Nozzle 4.1mm1
0558009425 Shield Cup 2.5mm
0558007624 Shield Cup 2.4mm
0558006130 Shield Cup 3mm
0558006141 Shield Cup 4.1mm
0558006166 Shield Cup 6.6mm
0558006199 Shield Cup 9.9mm
0558003924 Electrode Holder
0558005457 Baffle, 4 Hole x 0.0221
0558002534 Baffle, 4 Hole x 0.032 CCW1
0558002533 Baffle, 4-Hole x 0,0321
0558001625 Baffle, 8-Hole x 0.0471
0558002530 Baffle, 8-Hole x 0.047 CCW1
0004470031(21944) Diffuser
0004470115R Diffuser
0004470046 (37081) Shield Retaing Cap
0004470045 (37082) Nozzle Retaining Cap
0004450043 Nozzle Retaining Cap 25-40mm
0004450045 Nozzle Retaining Cap 60-100mm
0004450046 Shield Retaing Cap
0558012000 Electrode
0558011619 Nozzle 1.9mm(.073") 200A
0558010722 Nozzle 2.2mm 260A
0558011625 Nozzle 2.5mm 300A
0558009520 Shield Micro 2.0mm
0558009525 Shield Micro 2.5mm
0558009551 Shield 5.1mm(.200")
0558009550 Nozzle Retaining Cap
0558009548 Shield Retaing Cap
0558003804 Torch Body

Technical Support:
Plasma cutting is a process that cuts through electrically conductive materials by means of an accelerated jet of hot plasma. Typical materials cut by this process include steel, aluminum, brass and copper though other conductive metals may be cut as well. Plasma cutting is often used in fabrication and welding shops, automotive repair and restoration, industrial construction, salvage and scrapping operations. Due to the high speed, precision cuts, combined with low cost of operation, plasma cutting sees a widespread usage from large scale industrial CNC applications down to small hobbyist shops.
The basic plasma cutting process involves creating an electrical channel of ionized gas i.e. plasma from the plasma cutter itself, through the work piece to be cut, thus forming a completed electric circuit back to the plasma cutter via a grounding clamp. This is accomplished by a compressed gas (oxygen, air, inert and others depending on material being cut) which is blown through a focused nozzle at high speed toward the work piece. An electrical arc is then formed within the gas, between an electrode near or integrated into the gas nozzle and the work piece itself. The electrical arc ionizes some of the gas, thereby creating an electrically conductive channel of plasma. As electricity from the cutter torch travels down this plasma it delivers sufficient heat to melt through the work piece. At the same time, much of the high velocity plasma and compressed gas blow the hot molten metal away, thereby separating i.e. cutting through the work piece.
Plasma cutting is an effective means of cutting thin and thick materials alike. Hand-held torches can usually cut up to38mm thick steel plate, and stronger computer-controlled torches can cut steel up to 150 mm thick.[1] Since plasma cutters produce a very hot and very localized "cone" to cut with, they are extremely useful for cutting sheet metal in curved or angled shapes.
