Plasma Cutter Nozzle .11.848.311.614 G2514 For Kjellberg Plasma Cutting Machine

Plasma Cutter Nozzle .11.848.311.614 G2514 For Kjellberg Plasma Cutting Machine

  • Plasma Cutter Nozzle .11.848.311.614 G2514 For Kjellberg Plasma Cutting Machine
  • Plasma Cutter Nozzle .11.848.311.614 G2514 For Kjellberg Plasma Cutting Machine
Plasma Cutter Nozzle .11.848.311.614 G2514 For Kjellberg Plasma Cutting Machine
Product Details:
Place of Origin: China
Brand Name: Plasma Consumables
Certification: ROHS/ SGS
Model Number: .11.848.311.614 G2514
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: negotiation
Packaging Details: Manufacturer packing
Delivery Time: Prompt goods
Payment Terms: T/T or western Union
Supply Ability: 10,000pcs per month
Contact Now
Detailed Product Description
Product Name: Plasma Consumables Application: Plasma Cutting Machine
Standard: Manufacturer Production Standard Type: .11.848.311.614 G2514
High Light:

powermax 1650 parts

,

plasma torch parts

Plasma Cutter Nozzle .11.848.311.614 G2514 For Kjellberg Plasma Cutting Machine



1. HEC Brand

We make metal cutting system and plasma cutter as well as torch and consumables. We make plasma cutting machine and fiber laser cutting machine with high quality and reliablity.

2. Cut Performance

HEC plasma consumables use high quality material and standard process to make sure the highest quality. Our consumables cutting performance is as the same as orginial OEM manufactory.

3. Good Price

HEC plasma consumables are good quality with low price make customers best requirement and saving money.

4. Big Catagory

HEC sell all kinds of plasma consumables include , EASB, Kjellberg, Koike and also supply some torch.





Machine HEC NO. Thum NO. Ref NO. Description





















































Hifocus 280i

Hifocus 360i

Hifocus 440i

(Carbon Steel)

K94211 G901Y .11.848.201.142 Cooling tube
K94212 G902Y .11.852.201.142 Cooling tube
K94241 G931Y .11.848.401.142 Cooling tube
K0402 G002Y .11.848.221.300 Cathode O2
K0105 G015Y .11.848.231.350 Cathode O2
K0101 G011Y .11.848.231.320 Cathode O2
K0106 G016Y .11.848.231.360 Cathode O2
K0402 G092Y .11.848.401.310 Cathode O2
K7441 G101 .11.848.221.145 Gas guide
K1466 G2006 .11.848.221.406 Nozzle O2 25A
K1467 G2007 .11.848.221.407 Nozzle O2 35A
K54124 G3004 .11.848.201.1604 Nozzle cap
K641515 G4015 .11.848.201.1515 Swirl gas cap
K641220 G4020 .11.848.201.1520 Swirl gas cap
K44191 G501 .11.848.201.081 Protective cap
K0403 G003Y .11.848.221.310 Gathode -O2
K7442 G102 .11.848.221.146 Gas guide
K1466 G2006Y .11.848.221.406 Nozzle O2
K1467 G2007Y .11.848.221.407 Nozzle O2
K1468 G2008Y .11.848.221.408 Nozzle O2 50A
K14610 G2010Y .11.848.221.410 Nozzle O2 80A
K14612 G2012Y .11.848.221.412 Nozzle O2 120A
K14614 G2014Y .11.848.221.414 Nozzle O2 160A
K14616 G2016Y .11.848.221.416 Nozzle O2 200A
K14826 G2326Y .11.848.221.426 Nozzle
K14830 G2330Y .11.848.221.430 Nozzle
K14831 G2331Y .11.848.221.431 Nozzle
K11014 G2514 .11.848.311.614 Nozzle
K11015 G2515 .11.848.311.615 Nozzle
K11016 G2516 .11.848.311.616 Nozzle
K11018 G2518 .11.848.311.618 Nozzle
K11125 G2725 .11.848.411.625 Nozzle
K11127 G2727 .11.848.411.627 Nozzle
K11129 G2729 .11.848.411.629 Nozzle
K541228 G3028 .11.848.201.1628 Nozzle cap
K641522 G4022 .11.848.201.1522 Swirl gas cap
K641525 G4025 .11.848.201.1525 Swirl gas cap
K641530 G4030 .11.848.201.1530 Swirl gas cap
K04242 G032Y .11.848.421.310 Cathode O2
K04244 G034Y .11.848.421.330 Cathode O2
K74251 G121 .11.848.421.145 Gas guide
K14826 G2326Y .11.848.421.426 Nozzle O2 280A
K14830 G2330Y .11.848.421.430 Nozzle O2 360A
K14831 G2331Y .11.848.421.431 Nozzle -O2-400A
K541409 G3209 .11.848.401.1609 Nozzle cap
K541419 G3219 .11.848.401.1619 Nozzle cap
K541429 G3229 .11.848.401.1629 Nozzle cap
K641745 G4345 .11.848.401.1545 Swirl gas cap
K641750 G4350 .11.848.401.1550 Swirl gas cap
K641755 G4355 .11.848.401.1555 Swirl gas cap
K44201 G521 .11.848.401.081 Protective cap
K94211 G901Y .11.848.201.142 Water Tube
K94212 G902Y .11.852.201.142 Water Tube
K94241 G931Y .11.848.401.142 Water Tube



Technical Support:

Plasma cutting is a process that cuts through electrically conductive materials by means of an accelerated jet of hot plasma. Typical materials cut by this process include steel, aluminum, brass and copper though other conductive metals may be cut as well. Plasma cutting is often used in fabrication and welding shops, automotive repair and restoration, industrial construction, salvage and scrapping operations. Due to the high speed, precision cuts, combined with low cost of operation, plasma cutting sees a widespread usage from large scale industrial CNC applications down to small hobbyist shops.



Process:

The basic plasma cutting process involves creating an electrical channel of ionized gas i.e. plasma from the plasma cutter itself, through the work piece to be cut, thus forming a completed electric circuit back to the plasma cutter via a grounding clamp. This is accomplished by a compressed gas (oxygen, air, inert and others depending on material being cut) which is blown through a focused nozzle at high speed toward the work piece. An electrical arc is then formed within the gas, between an electrode near or integrated into the gas nozzle and the work piece itself. The electrical arc ionizes some of the gas, thereby creating an electrically conductive channel of plasma. As electricity from the cutter torch travels down this plasma it delivers sufficient heat to melt through the work piece. At the same time, much of the high velocity plasma and compressed gas blow the hot molten metal away, thereby separating i.e. cutting through the work piece.

Plasma cutting is an effective means of cutting thin and thick materials alike. Hand-held torches can usually cut up to38mm thick steel plate, and stronger computer-controlled torches can cut steel up to 150 mm thick.[1] Since plasma cutters produce a very hot and very localized "cone" to cut with, they are extremely useful for cutting sheet metal in curved or angled shapes.

COOLING PLASMA CUTTING SYSTEM CONSUMABLES AND RELATED SYSTEMS AND METHODS

In some aspects, electrodes can include a front portion shaped to matingly engage a nozzle of the plasma cutting system, the front portion having a first end comprising a plasma arc emitter disposed therein; and a rear portion thermally connected to a second end of the front portion, the rear portion shaped to slidingly engage with a complementary swirl ring of the plasma cutting system and including: an annular mating feature extending radially from a proximal end of the rear portion of the electrode to define a first annular width to interface with the swirl ring, the annular mating feature comprising a sealing member configured to form a dynamic seal with the swirl ring to inhibit a flow of a gas from a forward side of the annular mating feature to a rearward side of the annular mating feature.
