Electroce 220037 Powermax 1650 parts / PowerMax1250 Plasma consumables

Electroce 220037 Powermax 1650 parts / PowerMax1250 Plasma consumables

    •  Electroce 220037  Powermax 1650 parts  / PowerMax1250 Plasma consumables
  •  Electroce 220037  Powermax 1650 parts  / PowerMax1250 Plasma consumables

    Product Details:

    Place of Origin: China
    Brand Name: Plasma Consumables
    Certification: ROHS/ SGS
    Model Number: 220037

    Payment & Shipping Terms:

    Minimum Order Quantity: 5pcs
    Price: negotiation
    Packaging Details: Manufacturer packing
    Delivery Time: Prompt goods
    Payment Terms: T/T or western Union
    Supply Ability: 10,000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Plasma Consumables Application: Plasma Cutting Machine
    Standard: Manufacturer Production Standard Type: Electroce 220037
    High Light:

    plasma torch parts

    ,

    plasma cutter parts

    Electroce 220037 PowerMax1650 / PowerMax1250 Plasma consumables

                We can offer you all plasma consumables for , Kjellberg, Esab, Koike, Komatsu, Thermadyne, such as: electrode, nozzle, shield, swirl ring, inner cap, retaining cap, water tube, torch body and so on.
    Each of our products has been tested with a rigorous precision instrument, A large number of piercings tests and service life tests, And made batch trial in our customers. If all results are good, then we will producing them.



    Machine HEC NO. Ref NO. Description


















    PowerMAX45
    PowerMAX1250
    PowerMAX 1650

    H71925 120925 Swirl Ring 40/60/80Amp
    H71051 220051 Swirl Ring 100Amp
    H01926 120926 Electrode 40/60/80Amp
    H01037 220037 Electrode 100Amp
    H11932 120932 Nozzle 40Amp
    H11931 120931 Nozzle 60Amp
    H11927 120927 Nozzle 80Amp
    H11011 220011 Nozzle 100Amp
    H11006 220006 Nozzle 40Amp Without Cap
    H11007 220007 Nozzle 60Amp Without Cap
    H11980 120980 Nozzle 80Amp Without Cap
    H11064 220064 Nozzle 100Amp Without Cap
    H11329 220329 Nozzle 40Amp Fine Cut
    H41928 120928 Retaining Cap 40/60/80Amp
    H41048 220048 Retaining Cap 100Amp
    H41061 220061 Retaining Cap 40/60/80Amp
    H41206 220206 Retaining Cap 100Amp
    H21930 120930 Shield 40/60/80Amp
    H21047 220047 Shield 100Amp
    H21979 120979 Shieldg 40/60/80/100Amp
    H21325 220325 Shieldg 40Amp Fine Cut
    H31404 220404 Shieldg 40Amp Fine Cut
    H81767 128767 T100Torch Body
    H82768 128768 T100 Torch Head
    H91755 128755 T100 Torch Lead
    H91752 128752 T100 Torch Lead
    H81754 128754 Torch Main Body
    H91643 128643 Mounting Sleeve
    H91710 128710 Positioning Sleeve
    H91753 128753 Torch Lead
    H91751 128751 Torch Lead
    H91759 128759 Torch Lead
    H91519 058519 Torch O-ring



































































    Technical Support:
    plasma cutting arc fault analysis

    1. air pressure is too low

    Plasma cutting machine work, such as work pressure far below specifications required pressure, which means that the plasma arc jet velocity weakening, input the air flow is less than the specified value, this form of high energy and high speed of plasma arc, causing the incision quality is poor, cut through, incision tumor of the product phenomenon. The reasons for the lack of air pressure: air compressor input is insufficient, the pressure of the cutting machine air regulator is too low, there are oil pollution in the solenoid valve, the gas path is not smooth, etc.. The solution is to use before the observation of air compressor output pressure display, such as does not meet the requirements, can adjust the pressure or maintenance of air compressor. If the input pressure has reached the requirements, should check air filter relief pressure valve regulation is correct; gauge display can meet the cutting requirements. Otherwise deal with air filter pressure relief valve to carry out routine maintenance, to ensure that the input air dry, no oil. If you enter the air quality is poor, will cause the oil pollution in the valve, the valve is difficult to open, the valve port can not be fully opened. In addition, torch nozzle pressure is too low, the replacement valve; gas road section variable is caused by pressure is too low, according to the specifications for tracheal replacement.
